航空・宇宙機器用共通部品

クランプ類

クランプ類

クランプ(CLAMP)には、航空計器類取り付け用専用クランプをはじめ、一般電線固縛用、エンジン廻りの高温チューブ固定用耐熱クランプ等があります。
また、機体内のあらゆる配管やホース類を固定する為のクランプ類もあります。

ボンディングジャンパー

ボンディングジャンパー

ジャンパー(JUMPER)は機体と搭載している電子機器類との電位差をなくすために、両者の間を電気的に接続し、電気的平衡を維持させるための部品です。

ワッシャー・シム類

ワッシャー・シム類

あらゆる接合面の安定維持に欠くことのできない部品です。
ワッシャー(WASHER)は、接合面の緩みの防止や、接合面の保護や電位差の緩衝等の目的で使用されます。
シム(SHIM)は、接合面の間隙を補完する目的で使用されます。

ファスナー類

ファスナー類

ブラケット・ファスナー(BRACKET・FASTENER)は機体の各部・各個所で、物と物を締結するために用いられる部品で、ボルト、ナット、リベットなどが含まれます。

取扱製品

部品番号 品 名
CLAMP
AN735 CLAMP, LOOP TYPE BONDING
AN737 CLAMP, HOSE, AIRCRAFT
AN742 CLAMP, PLAIN, LOOP TYPE SUPPORT, AIRCRAFT
AS21919 CLAMP, LOOP, CUSHION
M85052/1
(DoD認定品)
CLAMP, LOOP, CUSHION
MS122902 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122903 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122904 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122905 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122906 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122907 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122908 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122910 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122925 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS122927 CLAMP, LOOP TYPE SUPPORT (HEAT RESISTANT) .204HOLE
MS21103 CLAMP, PLAIN, SUPPORT, LOOP, AIRCRAFT TYPE1 CLASS A AND B
MS21919 CLAMP, CUSHIONED, SUPPORT, LOOP-TYPE, AIRCRAFT
MS21920 CLAMP, HOSE (FLAT BAND, 500゚F)
MS28042 CLAMP, INSTRUMENT MOUNTING, AIRCRAFT
MS35842 CLAMP, HOSE : LOW PRESSURE, TYPE "F"
NAS1715 CLAMP, CUSHIONED, LOOP-TYPE
T1101 CLAMP, CUSHIONED, LOOP-TYPE
T1103 CLAMP, CUSHIONED, LOOP-TYPE
T1104 CLAMP, CUSHIONED, CENTER MOUNTING
T1105 CLAMP, CUSHIONED, LOOP-MULTIPLE-TYPE
T1108 CLAMP, CUSHIONED, OPEN
T1109 CLAMP, CUSHIONED, LOOP-TYPE
T1110 CLAMP, CUSHIONED, SUPPORT, RECTANGULAR
T1111 CLAMP, U-TYPE
T1112 CLAMP, CUSHIONED, LOOP-TYPE
T1114 CLAMP, TEFLON-CUSHIONED, RECTANGULAR
T1115 CLAMP, CUSHIONED, LOOP-MULTIPLE-TYPE
T1120 CLAMP, CUSHIONED, LOOP-TYPE
T1121 CLAMP, CUSHIONED, TUBE SUPPORT, LOOP-TYPE,
FOR HIGH TEMPERATURE
T1127 CLAMP, CUSHIONED, LOOP-RECTANGULAR-TYPE,
HINGE-LOOP, INTEGRAL BRACKET
T1129 CLAMP, CUSHIONED, HINGE-LOOP, TURN-FASTNER
T1151 CLAMP, CUSHIONED, LOOP-MULTIPLE-TYPE
T1152 CLAMP, LINE, SUPPORT, DUAL EQUAL, DIAMETER LINE
T1181 CLAMP, TUBE GRIP SUPPORT
T1194 CLAMP, LOOP-TYPE, TEFLON-COVER, SLOT
T1201 CLAMP, CUSHIONED, TUBE SUPPORT, LOOP-TYPE
T1202 CLAMP, CUSHIONED, TUBE SUPPORT, LOOP-TYPE
T1203 CLAMP, CUSHIONED, TUBE SUPPORT, LOOP-TYPE
T1205 CLAMP, CUSHIONED, LOOP-TYPE, FOR HIGH TEMPERATURE
T1735 CLAMP, LOOP-TYPE
T1842-1 CLAMP, HOSE
T1854 CLAMP, HOSE, LINER
JUMPER
M83413 JUMPER CABLE ASSEMBLY, LEAD, ELECTRICAL
MS25083 JUMPER ASSEMBLY, ELECTRIC, BONDING AND CURRENT RETURN
SS7039 JUMPER ASSEMBLY, ELECTRIC, BONDING AND CURRENT RETURN
部品番号 品 名
WASHER
AN122580 WASHER, PLAIN, STEEL
AN122581 WASHER, PLAIN, STEEL
AN122583 WASHER, PLAIN, STEEL
AN122584 WASHER, PLAIN, STEEL
AN122585 WASHER, PLAIN, STEEL
AN960 WASHER, FLAT
AN961 WASHER, FLAT, ELECTRICAL
AN970 WASHER, FLAT, FOR WOOD
AN975 WASHER, TAPER PIN
MS15795 WASHER, FLAT-METAL, ROUND, GENERAL PURPOSE
MS20002 WASHER, COUNTERSUNK AND PLAIN, HIGH STRENGTH
MS25440 WASHER, FOR USE WITH AIRCRAFT ALUMINUM TERMINALS
MS27111 WASHER, KEY-FLAT, GENERAL PURPOSE
MS27183 WASHER, FLAT(ROUND, STEEL,CADMIUM PLATED),
     GENERAL PURPOSE
MS9276 WASHER, KEY-CRES, AMS 5510, 180゚ LOCKING
MS9321 WASHER, FLAT, AMS 5510
MS9549 WASHER, FLAT, AMS 5510
MS9581 WASHER, KEY-CRES, AMS 5510, 90゚ LOCKING
MS9880 WASHER, CUP, LOCK, CRES AMS 5510
NAS1169 WASHER, DIMPLED, 100゚
NAS460 WASHER, TAB TYPE
NAS620 WASHER, FLAT
NAS1149 WASHER, FLAT
NAS1195 SHIM, MINIATURE ANCHOR NUT
NAS1197 WASHER, 5052 ALUMINUM ALLOY
NAS1401 WASHER, RADIUS
NAS391 WASHER, COUNTERSUNK, FINISHING
NAS463 NUT SPACER, PLATE, PLAIN
NAS500 NUT SPACER, PLATE, COUNTERSUNK
FASTENER
AN227 FASTENER, SNAP AND CURTAIN
AN240 EYELET-LACING
AN3053 FERRULE, RIGID CONDUIT
AN743 BRACKET, SUPPORT CLAMP
AN901 GASKET, METAL TUBE CONNECTION SEAL
MS20230 GROMMETS, METALLIC, PLAIN AND SPUR, WITH WASHERS
MS33737 NUT, SHEET SPRING, INSTRUMENT MOUNTING
MS35769 GASKET, METALLIC-ENCASED, ANNULAR, COPPER AND ASBESTOS
NAS1523 PACKING WITH RETAINER
NAS1711 STRAP, RETAINING, CUSHIONED, RECTANGULAR, OPEN BUTTOM
NAS487 NUT, INSTRUMENT MOUNT
NAS578 RETAINER, FLOATING BARREL NUT
T1437 STRAP, RETAINING, BAREMETAL, TWO HOLE MOUNTING
T1558 STRAP, RETAINING, CUSHIONED, TUBE SUPPORT,
TWO HOLE MOUNTING
T1860 STRAP, LINE SUPPORT, OPEN, TWO HOLE MOUNTING
T1902 BRACKET, SUPPORT CLAMP
T5000 LATCH ASSEMBLY, FLASH, TRIGGER ACTION
T5100 LATCH ASSEMBLY, FLASH, TRIGGER ACTION


上の表の製品は日本国内向けに販売しており、海外への輸出は行っておりません。
We only provide our products in the table above for domestic market, make no export for abroad.
